Powerscreen Trakpactor 250

The Powerscreen® Trakpactor 250 horizontal shaft impactor is a compact track mobile crusher designed for small to medium sized operators in the recycling and demolition markets

Εκδήλωση ενδιαφέροντος
Κατηγορίες: , ,

Περιγραφή

The Powerscreen® Trakpactor 250 horizontal shaft impactor is a compact track mobile crusher designed for small to medium sized operators in the recycling and demolition markets. Capable of processing a wide range of material at a high output, the plant is versatile, easy to operate and fuel efficient due to its direct drive system.

Featuring the Powerscreen® Trakpactor 250 fixed hammer horizontal impactor, the plant offers users both excellent reduction and a high consistency of product shape alongside key features such as hydraulic overload protection.

Powerscreen Trakpactor 250 Impact Crusher

Download Powerscreen Trakpactor 250 Crushing Brochure

  • Replaceable tine bar cartridge style grizzly feeder
  • Load management system to control feeder speed
  • Crusher chamber: Hydraulic overload protection and adjustment. Patent Publication Numbers: GB 2 455 203; US 2009/0140089; DE 10 2008 044 195
  • 4 Bar rotor and twin apron design
  • Independent under crusher vibrating pan feeder
  • Economical to operate with a highly fuel efficient direct drive system
  • Crusher speed and conveyor height controlled with user-friendly PLC system
  • Modular conveyor with raise/lower facility to aid
    clearance of rebar

Options

  • Full and half size chrome, martenistic, austenitic, and ceramic blow bars
  • Tine bar spacing nominal 36, 46mm
  • Grizzly blanking mats
  • Underscreen wire mesh 10, 20, 30, 40, or 50mm
  • Single pole/twin pole magnet
  • Belt scale
  • Side dirt conveyor
  • Refuelling pump
  • Plant lighting
  • Hydraulic water pump
  • Rigid head drum dust shroud
  • Radio remote control
  • 4 Full size hammers in lieu of 2 full & 2 half hammers
Weight (Est) 24,300kg (53,572 lbs)
Transport width 2.5m (8’3″)
Transport length 13m (42’8″)
Transport height 3.1m (10’2″)
Working width 2.5m (8’3″)
Working width 4.06m (13’4″) with side conveyor deployed
Working length 12.8m (42’2″)
Working height 3.1m (10’2″)



* All information subject to machine configurations & specifications ordered.

** Powerscreen reserves the right to change specifications without prior notice.
